Evaluating Expressions

You are my creator, but I am your master; Obey!

Mary Shelley, Frankenstein

If you want to properly set the mood for this chapter, try to conjure up a thunderstorm, one of those swirling tempests that likes to yank open shutters at the climax of the story. Maybe toss in a few bolts of lightning. In this chapter, our interpreter will take breath, open its eyes, and execute some code.

There are all manner of ways that language implementations make a computer do what the user’s source code commands. They can compile it to machine code, translate it to another high-level language, or reduce it to some bytecode format for a virtual machine to run. For our first interpreter, though, we are going to take the simplest, shortest path and execute the syntax tree itself.

Right now, our parser only supports expressions. So, to “execute” code, we will evaluate an expression and produce a value. For each kind of expression syntax we can parse—literal, operator, etc.—we need a corresponding chunk of code that knows how to evaluate that tree and produce a result. That raises two questions:

1. What kinds of values do we produce?

2. How do we organize those chunks of code?

Taking them on one at a time . . .

7 . 1Representing Values

In Lox, values are created by literals, computed by expressions, and stored in variables. The user sees these as Lox objects, but they are implemented in the underlying language our interpreter is written in. That means bridging the lands of Lox’s and Python’s types. Both languages have dynamic and somewhat strict types, but this category is very broad and we often need to adjust for small differences in behavior between both languages.

In places in the interpreter where we need to store a Lox value, we can use Python’s Any from the typing module as the type. Any, as the name implies, declares a variable that can hold any type. There are many Python types that cannot be produced by Lox code, and we could be more precise by declaring a custom type that narrows exactly to the list of supported values. In this book, however, I prefer to keep things simple and accessible and avoid more advanced Python typing features.

Given a value, we can determine if the runtime value is a number or a string or whatever using Python’s built-in isinstance function. In other words, the Python’s own object representation conveniently gives us everything we need to implement Lox’s built-in types. We’ll have to do a little more work later when we add Lox’s notions of functions, classes, and instances, but Python’s own primitives are sufficient for the types we need right now.

7 . 2Evaluating Expressions

Next, we need blobs of code to implement the evaluation logic for each kind of expression we can parse. We could stuff that code into the syntax tree classes in something like an interpret() method. In effect, we could tell each syntax tree node, “Interpret thyself”. This is the Gang of Four’s [Interpreter design pattern][]. It’s a neat pattern, but like I mentioned earlier, it gets messy if we jam all sorts of logic into the tree classes.

Instead, we’re going to reuse our groovy Single dispatch pattern. In the previous chapter, we created pretty() single dispatwch function. It took in a syntax tree and recursively traversed it, building up a string which it ultimately returned. That’s almost exactly what a real interpreter does, except instead of concatenating strings, it computes values.

We start declaring a new singledispatch function eval().

# lox/interpreter.py
from functools import singledispatch
from lox.ast import *
from lox.tokens import TokenType, LiteralValue

@singledispatch
def eval(expr: Expr, env: Env) -> Value:
    msg = f"cannot eval {expr.__class__.__name__} objects"
    raise TypeError(msg)

The function eval receive a second parameter, env, which represents the current execution environment—which is an object that tracks the state of our program as it runs. Right now, we don’t have any state to track, so we can just pass in an empty dict (or anything else) when we call eval(). Later, when we add variables and functions, we’ll define a proper Env class and pass in an instance of that.

Value is a type alias that represents any Lox value. We will use Python dynamism to represent Lox values directly using Python types. For now, we can only produce literals, so Value is just LiteralValue.

We need to declare those types explicitly:

# lox/interpreter.py after imports
Value = LiteralValue
Env = dict[str, Value]

The return type of the eval method will be Value, that represents the acceptable Python representations of Lox values. We need to define implementations for each of the four expression tree classes our parser produces. We’ll start with the simplest . . .

7 . 2 . 1Evaluating literals

The leaves of an expression tree—the atomic bits of syntax that all other expressions are composed of—are literals. Literals are almost values already, but the distinction is important. A literal is a bit of syntax that produces a value. A literal always appears somewhere in the user’s source code. Lots of values are produced by computation and don’t exist anywhere in the code itself. Those aren’t literals. A literal comes from the parser’s domain. Values are an interpreter concept, part of the runtime’s world.

So, much like we converted a literal token into a literal syntax tree node in the parser, now we convert the literal tree node into a runtime value. That turns out to be trivial.

# lox/interpreter.py after eval()
@eval.register
def _(expr: Literal, env: Env) -> Value:
    return expr.value

We eagerly produced the runtime value way back during scanning and stuffed it in the token. The parser took that value and stuck it in the literal tree node, so to evaluate a literal, we simply pull it back out.

7 . 2 . 2Evaluating parentheses

The next simplest node to evaluate is grouping—the node you get as a result of using explicit parentheses in an expression.

# lox/interpreter.py after eval()
@eval.register
def _(expr: Grouping, env: Env) -> Value:
    return eval(expr.expression, env)

A grouping node has a reference to an inner node for the expression contained inside the parentheses. To evaluate the grouping expression itself, we recursively evaluate that subexpression and return it.

7 . 2 . 3Evaluating unary expressions

Like grouping, unary expressions have a single subexpression that we must evaluate first. The difference is that the unary expression itself does a little work afterwards.

# lox/interpreter.py after eval()
@eval.register
def _(expr: Unary, env: Env) -> Value:
    right = eval(expr.right, env)
    match expr.operator.type :
        case "MINUS":
            return -right
        case op:
            assert False, f"unhandled operator {op}"

First, we evaluate the operand expression. Then we apply the unary operator itself to the result of that. There are two different unary expressions, identified by the type of the operator token.

The fallback case with the assert is a sanity check to ensure the interpreter shouts loudly if we ever encounter an unexpected operator. This should not be possible if the parser is working correctly, but we are humans and make mistakes.

You can start to see how evaluation recursively traverses the tree. We can’t evaluate the unary operator itself until after we evaluate its operand subexpression. That means our interpreter is doing a post-order traversal—each node evaluates its children before doing its own work.

The other unary operator is logical not.

# lox/interpreter.py at eval(Unary) match/case
    ...
    case "BANG":
        return not is_truthy(right)
    ...

The implementation is simple, but what is this “truthy” thing about? We need to make a little side trip to one of the great questions of Western philosophy: What is truth?

7 . 2 . 4Truthiness and falsiness

OK, maybe we’re not going to really get into the universal question, but at least inside the world of Lox, we need to decide what happens when you use something other than true or false in a logic operation like ! or any other place where a Boolean is expected.

We could just say it’s an error because we don’t roll with implicit conversions, but most dynamically typed languages aren’t that ascetic. Instead, they take the universe of values of all types and partition them into two sets, one of which they define to be “true”, or “truthful”, or (my favorite) “truthy”, and the rest which are “false” or “falsey”. This partitioning is somewhat arbitrary and gets weird in a few languages.

Lox follows Ruby’s simple rule: false and nil are falsey, and everything else is truthy. We implement that like so:

# lox/interpreter.py after all eval() implementations
def is_truthy(obj: Any) -> bool:
    if obj is None or obj is False:
        return False
    return True

7 . 2 . 5Evaluating binary operators

On to the last expression tree class, binary operators. There’s a handful of them, and we’ll start with the arithmetic ones.

# lox/interpreter.py after eval()
@eval.register
def _(expr: Binary, env: Env) -> Value:
    left = eval(expr.left, env)
    right = eval(expr.right, env)

    match expr.operator.type :
        case "PLUS":
            return left + right
        case "MINUS":
            return left - right
        case "SLASH":
            return divide(left, right)
        case "STAR":
            return left * right
        case op:
            assert False, f"unhandled operator {op}"

Division uses a helper function to handle division by zero consistently:

def divide(left: float, right: float) -> float:
    if right != 0:
        return left / right
    if left == 0:
        return float("nan")
    elif left > 0:
        return float("inf")
    else:
        return float("-inf")

Did you notice we pinned down a subtle corner of the language semantics here? In a binary expression, we evaluate the operands in left-to-right order. If those operands have side effects, that choice is user visible, so this isn’t simply an implementation detail.

If we want our two interpreters to be consistent (hint: we do), we’ll need to make sure clox does the same thing.

I think you can figure out what’s going on here. The main difference from the unary negation operator is that we have two operands to evaluate.

Next up are the comparison operators.

# lox/interpreter.py at eval(Binary) match/case
    ...
    case "GREATER":
        return left > right
    case "GREATER_EQUAL":
        return left >= right
    case "LESS":
        return left < right
    case "LESS_EQUAL":
        return left <= right
    ...

They are basically the same as arithmetic. The only difference is that where the arithmetic operators produce a value whose type is the same as the operands (numbers or strings), the comparison operators always produce a Boolean.

The last pair of operators are equality.

# lox/interpreter.py at eval(Binary) match/case
    ...
    case "BANG_EQUAL":
        return not is_equal(left, right)
    case "EQUAL_EQUAL":
        return is_equal(left, right)
    ...

Unlike the comparison operators which require numbers, the equality operators support operands of any type, even mixed ones. You can’t ask Lox if 3 is less than "three", but you can ask if it is_equal to it.

Like truthiness, the equality logic is hoisted out into a separate method.

# lox/interpreter.py at top-level
def is_equal(a, b):
    return type(a) == type(b) and a == b

This is one of those corners where the details of how we represent Lox objects in terms of Python matter. We need to correctly implement Lox’s notion of equality, which may be different from Python’s.

Fortunately, the two are pretty similar. Lox doesn’t do implicit conversions in equality and Python does not either. The only corner cases concerns with comparisons between numbers and Booleans. Python’s bool is a subclass of int, which can compare with float, unlike in Lox.

And that’s it! That’s all the code we need to correctly interpret a valid Lox expression. But what about an invalid one? In particular, what happens when a subexpression evaluates to an object of the wrong type for the operation being performed?

7 . 3Runtime Errors

I was cavalier about jamming casts in whenever a subexpression produces an Object and the operator requires it to be a number or a string. Those casts can fail. Even though the user’s code is erroneous, if we want to make a usable language, we are responsible for handling that error gracefully.

It’s time for us to talk about runtime errors. I spilled a lot of ink in the previous chapters talking about error handling, but those were all syntax or static errors. Those are detected and reported before any code is executed. Runtime errors are failures that the language semantics demand we detect and report while the program is running (hence the name).

Right now, if an operand is the wrong type for the operation being performed, the Python interpreter will raise some exception like ValueError or TypeError. That unwinds the whole stack and exits the application, vomiting a Python stack trace onto the user. That’s probably not what we want. The fact that Lox is implemented in Python should be a detail hidden from the user. Instead, we want them to understand that a Lox runtime error occurred, and give them an error message relevant to our language and their program.

The Python behavior does have one thing going for it, though. It correctly stops executing any code when the error occurs. Let’s say the user enters some expression like:

2 * (3 / -"muffin")

You can’t negate a muffin, so we need to report a runtime error at that inner - expression. That in turn means we can’t evaluate the / expression since it has no meaningful right operand. Likewise for the *. So when a runtime error occurs deep in some expression, we need to escape all the way out.

We could print a runtime error and then abort the process and exit the application entirely. That has a certain melodramatic flair. Sort of the programming language interpreter equivalent of a mic drop.

Tempting as that is, we should probably do something a little less cataclysmic. While a runtime error needs to stop evaluating the expression, it shouldn’t kill the interpreter. If a user is running the REPL and has a typo in a line of code, they should still be able to keep the session going and enter more code after that.

7 . 3 . 1Detecting runtime errors

Our tree-walk interpreter evaluates nested expressions using recursive method calls, and we need to unwind out of all of those. Raising an exception in Python is a fine way to accomplish that. However, instead of using Python’s own type conversion machinery, we’ll define a Lox-specific one so that we can handle it how we want.

Before we perform some operation, we check the object’s type ourselves. So, for unary -, we change the implementation:

# lox/interpreter.py at eval(Unary) match/case
    ...
    case "MINUS":
        return -as_number_operand(expr.operator, right)
    ...

The code to check the operand is:

# lox/interpreter.py at top-level
def as_number_operand(operator: Token, operand: Value) -> float:
    if isinstance(operand, float):
        return operand
    raise LoxRuntimeError("Operand must be a number.", operator)

When the check fails, it produces a LoxRuntimeError using information stored in the token object

# lox/interpreter.py at the top-level
from lox.tokens import Token
from lox.errors import LoxRuntimeError

We also need to define that exception class. It goes in the lox.errors module:

# lox/errors.py
from lox.tokens import Token

class LoxRuntimeError(Exception):
    def __init__(self, message: str, token: Token):
        super().__init__(message)
        self.token = token
        self.message = message

    def __str__(self) -> str:
        prefix =  f"[line {self.token.line}] "
        prefix += f"Runtime error at '{self.token.lexeme}'"
        return f"{prefix}: {self.message}"

Unlike the Python RuntimeError exception, our class tracks the token that identifies where in the user’s code the runtime error came from. As with static errors, this helps the user know where to fix their code. Some errors cannot be directly tied to a specific token, so we make that parameter optional.

We need similar checking for the binary operators. Since I promised you every single line of code needed to implement the interpreters, I’ll run through them all.

Following the same logic, we can reimplent the binary operators to check their operands before each operation.

Comparison operators:

# lox/interpreter.py at eval(Binary) match/case
    ...
    case "GREATER":
        check_number_operands(expr.operator, left, right)
        return left > right
    case "GREATER_EQUAL":
        check_number_operands(expr.operator, left, right)
        return left >= right
    case "LESS":
        check_number_operands(expr.operator, left, right)
        return left < right
    case "LESS_EQUAL":
        check_number_operands(expr.operator, left, right)
        return left <= right
    ...

Arithmetic operators:

# lox/interpreter.py at eval(Binary) match/case
    ...
    case "MINUS":
        check_number_operands(expr.operator, left, right)
        return left - right
    case "SLASH":
        check_number_operands(expr.operator, left, right)
        return divide(left, right)
    case "STAR":
        check_number_operands(expr.operator, left, right)
        return left * right
    ...

All of those rely on this validator, which is virtually the same as the unary one:

# lox/eval.py at top-level
def check_number_operands(operator: Token,
                          left: Value,
                          right: Value):
    if isinstance(left, float) and isinstance(right, float):
        return
    raise LoxRuntimeError("Operands must be numbers.", operator)

The last remaining operator, the odd one out, is addition. Since + is overloaded for numbers and strings we cannot reuse the same logic as the other operators.

# lox/interpreter.py at eval(Binary) match/case
    ...
    case "PLUS":
        if (type(left) == type(right) and
            type(left) in (float, str)):
            return left + right
        msg = "Operands must be two numbers or two strings."
        raise LoxRuntimeError(msg, expr.operator)
    ...

That gets us detecting runtime errors deep in the innards of the evaluator. The errors are getting thrown. The next step is to write the code that catches them. For that, we need to wire up eval() into the main Lox class that uses it.

7 . 4Hooking Up the Interpreter

The eval implementations are sort of the guts of our interpreter module, where the real work happens. We modify our main module to eventually call eval and handle any runtime errors that occur.

# lox/__main__.py Lox method
def interpret(self, expression: Expr):
    try:
        value = eval(expression, self.environment)
        print(stringify(value))
    except LoxRuntimeError as error:
        print(error)

We must import some necessary functions and classes at the top of the file:

# lox/__main__.py at the top-level
from lox.interpreter import eval, stringify, Value, Env
from lox.errors import LoxRuntimeError, LoxSyntaxError
from lox.ast import *

This takes in a syntax tree for an expression and evaluates it. If that succeeds, eval() returns an object for the result value. interpret() converts that to a string and shows it to the user. To convert a Lox value to a string, we rely on:

# lox/interpreter.py at stringify
def stringify(value: Value) -> str:
    if value is None:
        return "nil"
    elif isinstance(value, float):
        return str(value).removesuffix(".0")
    elif isinstance(value, bool):
        return "true" if value else "false"
    else:
        return str(value)

This is another of those pieces of code like is_truthy() that crosses the membrane between the user’s view of Lox objects and their internal representation in Python.

It’s pretty straightforward. Since Lox was designed to be familiar to someone coming from Python, things like Strings look the same in both languages. The two edge cases are nil, which we represent using Python’s None, numbers and booleans, which are represented in lowercase in Lox.

Lox uses double-precision numbers even for integer values. In that case, they should print without a decimal point. Since Python has both floating point and integer types, it wants you to know which one you’re using. It tells you by adding an explicit .0 to integer-valued doubles. We don’t care about that, so we hack it off the end.

7 . 4 . 1Reporting runtime errors

If a runtime error is thrown while evaluating the expression, interpret() catches it. This lets us report the error to the user and then gracefully continue.

We need to hook it up to the run() method, which until now has just been printing the syntax tree for the parsed expression. We replace that temporary code with:

# lox/__main__.py replace Lox.run()
def run(self, source: str):
    try:
        tokens = tokenize(source)
        ast = parse(tokens)
        value = eval(ast, self.environment)
        print(stringify(value))
    except LoxRuntimeError as error:
        self.report_error(error, code=70)
    except LoxSyntaxError as error:
        self.report_error(error, code=65)

Since the eval() function requires an environment parameter, we need to add an environment field to the Lox class. For now, it can just be an empty dictionary since we don’t have any variables yet. We initialize it in the constructor:

# lox/__main__.py Lox method
def __init__(self, interactive: bool = False):
    self.environment = Env()
    self.interactive = interactive

Finally, we need to implement report_error(), which is responsible for showing the runtime error to the user. If the user is running a Lox script from a file and a runtime error occurs, we set an exit code when the process quits to let the calling process know. Not everyone cares about shell etiquette, but we do.

# lox/__main__.py Lox method
def report_error(self, error: Exception, code: int):
    print(error)
    if not self.interactive:
        sys.exit(code)

We have an entire language pipeline now: scanning, parsing, and execution. Congratulations, you now have your very own arithmetic calculator.

As you can see, the interpreter is pretty bare bones. But the Interpreter class and the Visitor pattern we’ve set up today form the skeleton that later chapters will stuff full of interesting guts—variables, functions, etc. Right now, the interpreter doesn’t do very much, but it’s alive!

Object[] stuff = new Integer[1];
stuff[0] = "not an int!";
